🛠️ Arduino Nano IO Shield V1.0 🛠️
The Nano IO Shield V1.0 is an expansion board designed to extend the functionality of the Arduino Nano, offering convenient access to additional input/output (I/O) pins. It simplifies connections to sensors, motors, and modules, making prototyping easier and more organized.
✅ Technical Specifications:
- Version: Nano IO Shield V1.0.
- Compatibility: Works with Arduino Nano V3.0 and similar versions.
- Available Interfaces:
- Digital and analog GPIO pins.
- 5V and 3.3V power supply pins.
- I2C, UART, and SPI interfaces.
- Connectivity: Female headers for direct Nano insertion.
- Dimensions: ~54 × 38 × 15 mm.
- Approximate Weight: 20 g.
🔹 Key Features:
✔ Easy connection to sensors and modules.
✔ Supports I2C, SPI, and UART protocols.
✔ Compact design tailored for Arduino Nano.
✔ Reduces wiring complexity in projects.
✔ Ideal for education, hobby, and prototyping.
📌 Common Applications:
- Robotics and motion control projects.
- Arduino educational experiments.
- Sensor and measurement systems.
- IoT and smart systems development.
- DIY and small control systems.
