🔒 AS608 Fingerprint Sensor Module 🔒
The AS608 is a compact fingerprint sensor designed to detect, store, and match fingerprints with high accuracy. It supports enrolling, searching, and deleting fingerprints through UART communication, making it perfect for security projects and smart systems.
✅ Specifications:
- Model: AS608.
- Operating Voltage: 3.3V to 6V DC.
- Communication Interface: UART (Serial Interface).
- Fingerprint Recognition Speed: Less than 1 second.
- Storage Capacity: Up to approximately 1000 fingerprints.
- Built-in LED backlight for easier finger placement.
- Low power consumption in standby mode.
- Module dimensions: 50×20×20 mm.
🔹 Key Features:
✔ High-speed fingerprint registration and matching.
✔ Ability to store a large number of fingerprints internally.
✔ Compact and robust design suitable for mobile and fixed devices.
✔ Easy integration with microcontrollers like Arduino and Raspberry Pi.
✔ Simple and fast UART communication interface.
🔹 Weight: 30 grams
📌 Common Applications:
- Smart fingerprint door locks.
- Access control systems.
- Smart robotics and authentication projects.
- Smart attendance and time tracking systems.
- Security devices and professional Arduino projects.
