GY-906 MLX90614 Infrared Temperature Sensor - Contactless

🌡️ GY-906 MLX90614 Infrared Temperature Sensor - Contactless 🌡️

The GY-906 module uses the MLX90614 infrared sensor to measure temperature without physical contact. It is ideal for thermal monitoring applications in robotics, medical devices, smart systems, and industrial use where accuracy and safety are critical.

✅ Specifications:

• Sensor Type: MLX90614ESF-BAA (IR Thermometer)
• Measurement Type: Contactless infrared
• Measurement Range:
• Body: 32°C to 42.5°C
• Object: -70°C to +380°C
• Accuracy: ±0.5°C
• Communication Protocol: I2C
• Operating Voltage: 3.3V – 5V DC
• Field of View: ~90°
• Compact and easy to integrate

🔹 Key Features:

✔ Non-contact high-accuracy temperature measurement

✔ Easy interface with Arduino, ESP32, or Raspberry Pi

✔ Ideal for medical, industrial, and environmental projects

✔ Fast and stable response

✔ Low power consumption

🔹 Weight: 8 grams

📌 Common Applications:

• Remote human or object temperature sensing
• Thermal scanning and security systems
• Smart robotics projects
• Portable medical thermometers
• Intelligent HVAC systems
• IoT smart temperature monitoring
