🔄 SN74HC74N Dual D-Type Flip-Flop with Positive Edge Triggering 🔄
The SN74HC74N is a dual D-type flip-flop featuring two independent flip-flops, each with a positive edge-triggered clock input, along with asynchronous preset and clear inputs. It is widely used in data storage, counters, and digital signal processing applications.
✅ Technical Specifications:
- Number of Flip-Flops: 2
- Trigger Type: Positive Edge Triggered
- Preset and Clear Inputs: Asynchronous
- Operating Voltage Range: 2V to 6V
- Operating Temperature Range: -40°C to 85°C
- Propagation Delay: ~30ns at 6V
- Quiescent Current: 4µA
🔹 Key Features:
✔ Stable input and output locking for reliable signal processing.
✔ Wide voltage range compatibility for various digital systems.
✔ Ideal for counters, data storage, and frequency division applications.
✔ Compatible with embedded systems like Arduino & Raspberry Pi.
✔ Used in timing applications such as frequency division and digital data storage.
📌 Common Applications:
- Digital circuit design requiring data storage.
- Used in digital counters and frequency dividers.
- Robotics and embedded system projects.
- Digital signal conversion applications.
- Control of switching circuits and advanced logic gates.
🔹 Approximate Weight: 10g
